Tornado ECO 500-AW Series Recycling Carpet Extractor 98848
Tornado with CFR Technology
Tornado's portable Eco 500 series upright extractors equip carpet cleaning professionals with all of the tools required to achieve contractor-grade, deep-cleaning results. These ten and fifteen gallon workhorses are designed to meet a multitude of cleaning demands, and are equipped with all-new advanced technology, high-efficiency air-watt motors for increased cleaning performance.
Eco 500 series | Eco 500 AW | Eco 500 AWH | Eco 500 AW Plus | Eco 500 AWH Plus |
---|---|---|---|---|
Model | 98840 | 98844 | 98852 | 98854 |
Base Unit (machine only) | 98838 | 98842 | 98848 | 98846 |
Electric Heater | na | 110v, 1650w | na | 110v, 1650w |
Tank Size | 10 gal. | 10 gal. | 15 gal. | 15 gal. |
Machine Dimensions (Lxwxh) | 29" x 20" x 35" | 29" x 20" x 35" | 29" x 20" x 40" | 29" x 20" x 40" |
Body Weight | 86 lbs. | 96lbs | 88 lbs | 98 lbs |
Vacuum Motor | Single, 6.6 dia AW | single, 6.6 dia AW | single, 6.6 dia | single, 6.6 dia |
peak airwatts | 673 | 673 | 673 | 673 |
maximum cfm | 141 | 141 | 141 | 141 |
Solution Pump (adjustable p.s.i.) | 500 psi(34.5 bar) | 500 psi(34.5 bar) | 500 psi(34.5 bar) | 500 psi(34.5 bar) |
Pump Motored | 1/4 hp dc | 1/4 hp dc | 1/4 hp dc | 1/4 hp dc |
Power (v/amps) | 115v | 115v | 115v | 115v |
Power Cord | 25' detachable | 25' detachable | 25' detachable | 25' detachable |
Front Wheel Dimensions | two 4" dia. swivel casters | two 4" dia. swivel casters | two 4" dia. swivel casters | two 4" dia. swivel casters |
rear wheel Dimensions | two 10" dia. wheels | two 10" dia. wheels | two 10" dia. wheels | two 10" dia. wheels |
11" rapid recovery wand (type r) | included in kit | included in kit | included in kit | included in kit |
3" combination tool | included in kit | included in kit | included in kit | included in kit |
33' flexible hose - 1,500 p.s.i (1.5") | included in kit | included in kit | included in kit | included in kit |
Parts / Labor Warranty | 1 year* | 1 year* | 1 year* | 1 year* |
tank warranty | 5 year* | 5 year* | 5 year* | 5 year* |
User and Operations Manual - Eco 500 Series Download PDF
Product Brochure - Eco 500 - English Download PDF
User and Operations Manual - Pro 500-750 Download PDF
