Tornado Eco 500-AWH Plus Series Recycling Carpet Extractor With Kit 98854
Tornado with CFR Technology
Tornado's portable Eco 500 series upright extractors equip carpet cleaning professionals with all of the tools required to achieve contractor-grade, deep-cleaning results. These ten and fifteen gallon workhorses are designed to meet a multitude of cleaning demands, and are equipped with all-new advanced technology, high-efficiency air-watt motors for increased cleaning performance.
Eco 500 series | Eco 500 AW | Eco 500 AWH | Eco 500 AW Plus | Eco 500 AWH Plus |
---|---|---|---|---|
Model | 98840 | 98844 | 98852 | 98854 |
Base Unit (machine only) | 98838 | 98842 | 98848 | 98846 |
Electric Heater | na | 110v, 1650w | na | 110v, 1650w |
Tank Size | 10 gal. | 10 gal. | 15 gal. | 15 gal. |
Machine Dimensions (Lxwxh) | 29" x 20" x 35" | 29" x 20" x 35" | 29" x 20" x 40" | 29" x 20" x 40" |
Body Weight | 86 lbs. | 96lbs | 88 lbs | 98 lbs |
Vacuum Motor | Single, 6.6 dia AW | single, 6.6 dia AW | single, 6.6 dia | single, 6.6 dia |
peak airwatts | 673 | 673 | 673 | 673 |
maximum cfm | 141 | 141 | 141 | 141 |
Solution Pump (adjustable p.s.i.) | 500 psi(34.5 bar) | 500 psi(34.5 bar) | 500 psi(34.5 bar) | 500 psi(34.5 bar) |
Pump Motored | 1/4 hp dc | 1/4 hp dc | 1/4 hp dc | 1/4 hp dc |
Power (v/amps) | 115v | 115v | 115v | 115v |
Power Cord | 25' detachable | 25' detachable | 25' detachable | 25' detachable |
Front Wheel Dimensions | two 4" dia. swivel casters | two 4" dia. swivel casters | two 4" dia. swivel casters | two 4" dia. swivel casters |
rear wheel Dimensions | two 10" dia. wheels | two 10" dia. wheels | two 10" dia. wheels | two 10" dia. wheels |
11" rapid recovery wand (type r) | included in kit | included in kit | included in kit | included in kit |
3" combination tool | included in kit | included in kit | included in kit | included in kit |
33' flexible hose - 1,500 p.s.i (1.5") | included in kit | included in kit | included in kit | included in kit |
Parts / Labor Warranty | 1 year* | 1 year* | 1 year* | 1 year* |
tank warranty | 5 year* | 5 year* | 5 year* | 5 year* |
User and Operations Manual - Eco 500 Series Download PDF
Product Brochure - Eco 500 - English Download PDF
User and Operations Manual - Pro 500-750 Download PDF
