Electric Floor Machines
Certain environments can exact a heavy toll on even the most ruggedly designed cleaning equipment. Tornado’s® M Series of Floor Machines have it all when it comes to heavy-duty applications including rolled steel bases with non-marking soft bumper guards, a triple planetary gear system, and cast aluminum Start Guard I handle for added saftey, strength and operator comfort. The M Series features our heavy-duty, dual-capacitor, 1.5 HP motor with a high torque configuration and low-amp draw for the ultimate in power.
| Model | M 17" 175 RPM | M 20" 175 RPM |
|---|---|---|
| Catalog Number | 97590 | 97595 |
| Cleaning Path | 17 in. | 20 in. |
| Housing Construction | Rolled Steel | Rolled Steel |
| Motor Height | 16 in. | 16 in. |
| Capacity (Solution Tank) | 3 gal. (optional) | 3 gal. (optional) |
| Brush Design / Type | Rotary Disc | Rotary Disc |
| Disc RPM | 175 | 175 |
| Vac Motor | 1.5 HP | 1.5 HP |
| Power | 115V | 115V |
| Weight | 100 lbs. | 105 lbs. |
| Dimensions (L x W x H) | 23 in. x 17 in. x 49 in. | 26 in. x 20 in. x 49 in. |
| Rotary Diameter | 17" | 20" |
| Wheel Type | 5" Non-marking / Self-lubricating | 5" Non-marking / Self-lubricating |
| Handle Design | Cast Aluminum |
Cast Aluminum |
Product Brochure - M Series - English Download PDF
Users and Operations Manual - M Series - English-French-Spanish Download PDF
